Hikvision IC-S50 Mifare contactless smart card for use with Hikvision intercom

Hikvision IC-S50 Mifare contactless smart card for use with Hikvision intercom

22-03-2024 Hikvision IC-S50 Mifare contactless smart card for use with Hikvision intercom>
Brand:Hikvision
Product Code:IC-S50
Availability: Call us for availabillity

Tags: HIKVISION, IC-S50, MIFARE, CONTACTLESS, SMART CARD, INTERCOM

Hikvision IC-S50 Mifare contactless smart card for use with Hikvision intercom


The IC-S50 is an RFID access card for use with Hikvision Intercom Systems.


  • MIFARE RF Interface (ISO/IEC 14443 A)
  • Non-Contact data transmission and supplied power(no battery needed)
  • Working distance of no more than 100mm (depends on the antenna dimension)
  • Working frequency of 13.56 MHz
  • High data transmission speed: 106 k bit/s
  • Data integrity protection: 16 bit CRC, odd-even check, encoding and counting by bit.
  • Anti-conflict
  • Data transmission and processing time: < 100 ms (including backup and management time) EEPROM
  • 1 k byte (16 zones, 4 sections per zone, 16 bytes per section)
  • User definable reading/writing condition for memory block
  • Long time data storage: 10 years
  • 100,000 writes
  • Triple accreditation(ISO/IEC DIS9798-2)
  • Attack protective radio-frequency channel data encryption
  • Two security keys (support multiple security levels) for each section
  • Only one serial No. for one card
  • Transmission security key to protect the access right of EEPROM during the transmission
